BUTTERFLY VALVE GEAR TYPE
| NO | PART | MATERIAL | QTY |
|---|---|---|---|
| 1 | BODY | PVC,CPVC,PPG | 1 |
| 2 | SEAT SEAL | EPDM,FPM | 1 |
| 3 | DISC | PVC,CPVC,PPG | 1 |
| 4 | BOLT | 304 | 1 |
| 5 | STEM | STEEL/304/316 | 1 |
| 6 | O-RING | EPDM/FPM | 2 |
| 7 | KEY | STELL | 1 |
| 8 | GEAR BOX | IRON | 1 |
| 9 | HAND WHEEL | IRON | 1 |
| 10 | PIN | STELL | 1 |
| NO | PART | MATERIAL | QTY |
|---|---|---|---|
| 1 | BODY | PVC,CPVC,PPG | 1 |
| 2 | SEAT SEAL | EPDM,FPM | 1 |
| 3 | DISC | PVC,CPVC,PPG | 1 |
| 4 | BOLT | 304 | 1 |
| 5 | STEM | STEEL/304/316 | 1 |
| 6 | O-RING | EPDM/FPM | 2 |
| 7 | KEY | STELL | 1 |
| 8 | GEAR BOX | IRON | 1 |
| 9 | HAND WHEEL | IRON | 1 |
| 10 | PIN | STELL | 1 |
