ONE WAY FAUCET
| NO | PART | MATERIAL | QTY |
|---|---|---|---|
| 1 | NUt | ABS | 1 |
| 2 | BODY | PVC | 1 |
| 3 | SEAT SEAL | TPE | 2 |
| 4 | BALL | PVC | |
| 5 | HANDLE | PVC | 2 |
| 6 | UNION NUT | SS41 | 1 |
| 7 | HANDLE CAP | ABS |
| Size | NPT | BSPT | A | B | L1 | L2 | H1 | H2 |
|---|---|---|---|---|---|---|---|---|
| 15mm(1/2") | 14 | 14 | 13.8 | 17.7 | 62.5 | 92.9 | 56 | 80 |
| 20mm(3/4") | 14 | 14 | 13.8 | 17.7 | 63 | 92.9 | 55.6 | 81.5 |
