SINGLE UNION BALL VALVE III

NO PART MATERIAL QTY
1 Handle PVC-U 1
2 STEM O-RING nbr 1
3 SEAT SEAL PTFE 1
4 BALL PVC-U 1
5 O-RING NBR 1
6 BODY PVC-U 1
7 SEAT CARRIER PVC-U 1
8 END CONNECTOR PVC-U 1
9 SEAT CARRIER FLAT O-RING NBR 1
10 SEAT CARRIER O-RING NBR 1
11 UNION NUT PVC-U 1
12 STEM PVC-U 1

Size D1 D NPT NBR I L1 L2 L3 L4 H
15mm(1/2") 49 29 1/2" 20 18 38 58 80 57 50
20mm(3/4") 60 35 3/4" 25 18 41.9 66 88 64 49.7
25mm(1") 66 43.2 1" 32 22 49 76.7 101.9 77.2 62.3
32mm(1 1/4") 81 51 1 1/4" 40 29 59 93 125 91 75
40mm(1 1/2") 94 60 1 1/2" 50 31.5 63.2 99.2 133.2 100 81.5
50mm(2") 111 74 2" 63 38 84.4 124.7 165.7 117.6 92
80mm(3") 178 107.5 3" 85 56 108.4 172 229.3 173 138.6
100mm(4") 210 131 4" 110 66.2 135 212.4 281.1 224 151.65
ERA Valves PVC SINGLE UNION BALL VALVE III

ERA Valves PVC SINGLE UNION BALL VALVE III

A quarter-turn of the handle fully opens or closes the valve for quick shutoff. Full port allowing maximum flow and minimum pressure drop or turbulence.

System:

  • Easy turn handle means no pliers or breakage while turning on/off, and it's replaceable!
  • A quarter-turn of the handle fully opens or closes the valve for quick shutoff.
  • For use with distribution of pressurized liquids, which are chemically compatible with piping materials.
  • True union valves have a carrier that can be removed from the piping system when needed.
  • This allows you to repair or replace the carrier without completely disassembling the system, saving time and money.

Scope:

  • Our Single Union Ball Valve/true union ball valves are made from durable dark gray PVC VALVE and have an easy-to-grip red handle that turns with minimal effort.
  • For use with distribution of pressurized liquids, which are chemically compatible with piping materials.
  • Our PVC ball valves are not only durably and made from a heavy duty material - but also a very affordable and economic option to your project or service need.

Specification:

Please note - as temperature increases, working pressure decreases, the optimal working pressure for PVC VALVE is 150 psi at 73°F (22°C).

  • Material: PVC
  • Model: SINGLE UNION BALL VALVE III
  • Part Number: USU03
  • Pressure Rating: PN10 (F1970)
  • Certifications: NSF-pw & UPC
